Featured image of post 【分布式与并行计算】CUDA加速课程题目

【分布式与并行计算】CUDA加速课程题目

CUDA加速计算

1 加速向量加法

#include <stdio.h>
#include <assert.h>

inline cudaError_t checkCuda(cudaError_t result)
{
  if (result != cudaSuccess) {
    fprintf(stderr, "CUDA Runtime Error: %s\n", cudaGetErrorString(result));
    assert(result == cudaSuccess);
  }
  return result;
}

void initWith(float num, float *a, int N)
{
  for(int i = 0; i < N; ++i)
  {
    a[i] = num;
  }
}

__global__ void addVectorsInto(float *result, float *a, float *b, int N)
{
  int initIndex = threadIdx.x + blockIdx.x * blockDim.x;
  int gridStride = gridDim.x * blockDim.x;

  for(int i = initIndex;i<N;i+=gridStride){
   result[i] = a[i] + b[i];
  }
}

void checkElementsAre(float target, float *array, int N)
{
  for(int i = 0; i < N; i++)
  {
    if(array[i] != target)
    {
      printf("FAIL: array[%d] - %0.0f does not equal %0.0f\n", i, array[i], target);
      exit(1);
    }
  }
  printf("SUCCESS! All values added correctly.\n");
}

int main()
{
  const int N = 2<<20;
  size_t size = N * sizeof(float);

  float *a;
  float *b;
  float *c;

  cudaMallocManaged(&a, size);
  cudaMallocManaged(&b, size);
  cudaMallocManaged(&c, size);

  initWith(3, a, N);
  initWith(4, b, N);
  initWith(0, c, N);

  size_t threads_per_block = 1024;
  size_t number_of_blocks = (N+threads_per_block-1)/threads_per_block;

  addVectorsInto<<<32,1024>>>(c, a, b, N);
  //addVectorsInto<<<number_of_blocks,threads_per_block>>>(c, a, b, N);

  checkCuda(cudaGetLastError());
  checkCuda(cudaDeviceSynchronize());
  checkElementsAre(7, c, N);

  cudaFree(a);
  cudaFree(b);
  cudaFree(c);
}

2 加速SAXPY

#include <stdio.h>
#include <assert.h>
#define N 2048 * 2048 // Number of elements in each vector

/*
 * Optimize this already-accelerated codebase. Work iteratively,
 * and use nsys to support your work.
 *
 * Aim to profile `saxpy` (without modifying `N`) running under
 * 20us.
 *
 * Some bugs have been placed in this codebase for your edification.
 */


inline cudaError_t checkCuda(cudaError_t result)
{
  if (result != cudaSuccess) {
    fprintf(stderr, "CUDA Runtime Error: %s\n", cudaGetErrorString(result));
    assert(result == cudaSuccess);
  }
  return result;
}

__global__
void saxpy(float * a, float * b, float * c)
{
    int tid = blockIdx.x * blockDim.x + threadIdx.x;
    int stride = gridDim.x * blockDim.x;

    for(int i = tid; i<N; i+=stride){
        c[tid] = 2 * a[tid] + b[tid];
    }
}

int main()
{
    int deviceId;
    int numberOfSMs;
    cudaGetDevice(&deviceId);
    cudaDeviceGetAttribute(&numberOfSMs, cudaDevAttrMultiProcessorCount, deviceId);


    float *a, *b, *c;
    int size = N * sizeof (float); // The total number of bytes per vector
    cudaMallocManaged(&a, size);
    cudaMallocManaged(&b, size);
    cudaMallocManaged(&c, size);


    // Initialize memory
    for( int i = 0; i < N; ++i )
    {
        a[i] = 2.0;
        b[i] = 1.0;
        c[i] = 0.0;
    }
    cudaMemPrefetchAsync(a, size, deviceId);
    cudaMemPrefetchAsync(b, size, deviceId);
    cudaMemPrefetchAsync(c, size, deviceId);

    int threads_per_block = 256;
    int number_of_blocks = numberOfSMs * 32 ;
    saxpy <<< number_of_blocks, threads_per_block >>> ( a, b, c );
    checkCuda(cudaGetLastError());
    checkCuda(cudaDeviceSynchronize());


    // Print out the first and last 5 values of c for a quality check
    for( int i = 0; i < 5; ++i )
        printf("c[%d] = %f, ", i, c[i]);
    printf ("\n");
    for( int i = N-5; i < N; ++i )
        printf("c[%d] = %f, ", i, c[i]);
    printf ("\n");


    cudaFree( a ); cudaFree( b ); cudaFree( c );
}

3 N-body

#include <math.h>
#include <stdio.h>
#include <stdlib.h>
#include "timer.h"
#include "files.h"

#define SOFTENING 1e-9f

#include <assert.h>
inline cudaError_t checkCuda(cudaError_t result)
{
  if (result != cudaSuccess) {
    fprintf(stderr, "CUDA Runtime Error: %s\n", cudaGetErrorString(result));
    assert(result == cudaSuccess);
  }
  return result;
}

/*
 * Each body contains x, y, and z coordinate positions,
 * as well as velocities in the x, y, and z directions.
 */

typedef struct { float x, y, z, vx, vy, vz; } Body;

/*
 * Calculate the gravitational impact of all bodies in the system
 * on all others.
 */
__global__
void bodyForce(Body *p, float dt, int n) {
  int index = blockIdx.x * blockDim.x + threadIdx.x;
  int stride = gridDim.x * blockDim.x;
  for (int i = index; i < n; i+=stride) {
    float Fx = 0.0f; float Fy = 0.0f; float Fz = 0.0f;

    for (int j = 0; j < n; j++) {
      float dx = p[j].x - p[i].x;
      float dy = p[j].y - p[i].y;
      float dz = p[j].z - p[i].z;
      float distSqr = dx*dx + dy*dy + dz*dz + SOFTENING;
      float invDist = rsqrtf(distSqr);
      float invDist3 = invDist * invDist * invDist;

      Fx += dx * invDist3; Fy += dy * invDist3; Fz += dz * invDist3;
    }

    p[i].vx += dt*Fx; p[i].vy += dt*Fy; p[i].vz += dt*Fz;
  }
}


int main(const int argc, const char** argv) {

  // The assessment will test against both 2<11 and 2<15.
  // Feel free to pass the command line argument 15 when you gernate ./nbody report files
  int nBodies = 2<<11;
  if (argc > 1) nBodies = 2<<atoi(argv[1]);

  // The assessment will pass hidden initialized values to check for correctness.
  // You should not make changes to these files, or else the assessment will not work.
  const char * initialized_values;
  const char * solution_values;

  if (nBodies == 2<<11) {
    initialized_values = "files/initialized_4096";
    solution_values = "files/solution_4096";
  } else { // nBodies == 2<<15
    initialized_values = "files/initialized_65536";
    solution_values = "files/solution_65536";
  }

  if (argc > 2) initialized_values = argv[2];
  if (argc > 3) solution_values = argv[3];

  const float dt = 0.01f; // Time step
  const int nIters = 10;  // Simulation iterations

  int bytes = nBodies * sizeof(Body);
  float *buf;

  cudaMallocManaged(&buf, bytes);

  Body *p = (Body*)buf;

  read_values_from_file(initialized_values, buf, bytes);

  double totalTime = 0.0;

  /*
   * This simulation will run for 10 cycles of time, calculating gravitational
   * interaction amongst bodies, and adjusting their positions to reflect.
   */

  int deviceId;
  int numberOfSMs;
  cudaGetDevice(&deviceId);
  cudaDeviceGetAttribute(&numberOfSMs, cudaDevAttrMultiProcessorCount, deviceId);
  int threads_per_block = 128;
  int number_of_blocks = numberOfSMs * 25 ;

  for (int iter = 0; iter < nIters; iter++) {
    StartTimer();

  /*
   * You will likely wish to refactor the work being done in `bodyForce`,
   * and potentially the work to integrate the positions.
   */

    bodyForce<<<threads_per_block,number_of_blocks>>>(p, dt, nBodies); // compute interbody forces
    checkCuda(cudaGetLastError());
    checkCuda(cudaDeviceSynchronize());
  /*
   * This position integration cannot occur until this round of `bodyForce` has completed.
   * Also, the next round of `bodyForce` cannot begin until the integration is complete.
   */

    for (int i = 0 ; i < nBodies; i++) { // integrate position
      p[i].x += p[i].vx*dt;
      p[i].y += p[i].vy*dt;
      p[i].z += p[i].vz*dt;
    }

    const double tElapsed = GetTimer() / 1000.0;
    totalTime += tElapsed;
  }

  double avgTime = totalTime / (double)(nIters);
  float billionsOfOpsPerSecond = 1e-9 * nBodies * nBodies / avgTime;
  write_values_to_file(solution_values, buf, bytes);

  // You will likely enjoy watching this value grow as you accelerate the application,
  // but beware that a failure to correctly synchronize the device might result in
  // unrealistically high values.
  printf("%0.3f Billion Interactions / second", billionsOfOpsPerSecond);

  cudaFree(buf);
}

4 证书
